Mean Well LED Switching Power Supply - LPV Series 120W Single Output LED Power Supply - 12V DC
- Low cost, economical LED power supply, constant voltage
- Class II - no FG (all wattage versions)
- Protections: short circuit, over load, over voltage
- Universal AC input: 208-277 VAC
- Slim plastic case with IP67 level
- Withstand 300VAC surge input for 5 seconds
- -30~70℃ wide operation range
- Suitable for economical LED lighting and moving sign applications
- Low cost, high reliability
- 2 year warranty
- Made by Mean Well
- See 20-100-watt version.
NOTE: This is a 200~277V AC, not a standard 120V AC.
Specifications
Built-in PFC Function: No
Dimmable: No
Dimming Control: None
Efficiency (typical): 88%
Environmental Rating: Suitable for Wet Locations, Waterproof
IP Rating: IP67
Input Connection Type: Pigtail
Input Frequency Range: 47 ~ 63 Hz
Input Voltage: 200 ~ 277 VAC
Input Voltage Range: 200~277 VAC
Multi-Tap: No
Number of Outputs: 1
Operating Temperature: -25~+65 °C (-13~+149 °F)
Output Rated Current: 10.0A (10000mA)
Output Voltage: 12 VDC
Power Consumption: 120 Watts
Power Supply Type: Waterproof
Standards And Certifications: RoHS Compliant, UL Recognized
Type: Power Supplies
UL File Number: E320521
UL Standard Number: UL 8750
Wattage: 120 Watts
Package Weight: 1lb 14.2oz (0.86kg)
Package Dimensions: 11" (28cm) x 3.25" (8cm) x 1.73" (4cm)
In the past, constant-current LED power sources were referred to as LED drivers, and constant voltage LED power sources were called LED power supplies. Today, the terms are interchangeable.
All specifications are subject to change without notice.
