5mm Cool White LED - 7650K - T1 3/4 LED w/ 120 Degree Viewing Angle
5mm through hole Cool White LED. Features 7650K color temperature and 1,500mcd. It has a 120 degree viewing angle. Component LEDs are sensitive electronic devices and require some knowledge of electronic circuits to operate them. Price listed is per unit, however, bulk discounts are available and are automatically applied to your order.
Specifications
CCT Value: 7650K
Continuous Forward Current: 30 mA
Forward Voltage: 3.3V
LED Color: Cool White
LED Package: 5 mm (T-1 3/4)
Lens: Clear
Lumen: 5 Lumen
Maximum Forward Voltage: 3.8V
Millicandela: 1500mcd
Operating Temperature: -20~+80 °C (-4~+176 °F)
Peak Forward Current: 100mA
Power Consumption: 0.099 Watts
Power Dissipation: 120mW
Reverse Current: 10µA
Reverse Voltage: 5V
Storage Temperature: -30~+100 °C
Tube Diameter: T1-3/4
Viewing Angle: 120 degree
Package Weight: 0.01oz (0kg)
Package Dimensions: 0.39" (1cm) x 0.24" (1cm) x 0.24" (1cm)
