    5050 SMD LED - 3100K Warm White Surface Mount LED w/120 Degree Viewing Angle

      (3 Reviews) | Write a review
    SKU: 5050-WW6000
    Discontinued
    Starting at: $0.49
    • 30 Days Return
    • 5 Years Warranty
    Add to Wishlist
    Deliver between Sun,Dec,22 and Sat,Dec,28. order with 2days,9hrs and 31 min.

    This 5050 SMD 3 chip surface mount component LED in Warm White features 19 lumens of 3100K color temperature and a 120 degree viewing angle. See spectral graph for actual wavelength measurement. Price listed is per unit, however, bulk discounts are available and are automatically applied to your order. Also available in Pure White and Cool White.

    Specifications
    CCT Value:    2850K
    Continuous Forward Current:    3x20 mA
    CRI:    72 CRI
    Forward Voltage:    3.2V
    LED Color:    Warm White
    LED Package:    5mm x 5mm
    LED Type:    5050 SMD
    Lumen:    19 Lumen
    Maximum Forward Voltage:    3.4V
    Millicandela:    6000mcd
    Operating Temperature:    -20~+80 °C (-4~+176 °F)
    Peak Forward Current:    3x100mA
    Power Consumption:    0.192 Watts
    Power Dissipation:    3x120mW
    Reverse Voltage:    5V
    Storage Temperature:    -40~+85 °C
    Viewing Angle:    120 degree
    Package Weight: 0.01oz (0kg)
    Package Dimensions: 0.47" (1cm) x 0.17" (0cm) x 0.17" (0cm)
    All specifications are subject to change without notice.
